product-01

  • Fiber dry powder mixing machine - copy
Fiber dry powder mixing machine - copy

Fiber dry powder mixing machine - copy

  • volume:50L
  • main power:2.2kw
  • diffuser:4
  • weight:200kg
  • Product description: Fiber dry powder mixing machine
  • INQUIRY

Fiber dry powder mixing machine


Mixer purpose:“two high and two low”==high uniformity, high yield, low energy consumption, low noise.

Synchronous positive& negative powder mixer structure introduced. The mixing with double period of 180degrees of special material screw shaft structure, around, the mixing cylinder, from right to left, in turn, and the material has been implemented in boiling stir no dead Angle.

Replaceable blade fixed on the screw shaft, according to the needs of the hybrid materials, can be equipped with wear-resistant alloy blade, adjustable spacing.

Stir in the device is equipped with many fly knife, according to the need frequency conversation control speed, steering Angle and material orbit instead, moment to many scattered, especially suitable for fiber mixture.

Double speed dynamic reduction stand and the cylinder direct connection, compact structure, smooth, no vibration during operation are, low noise.

Mix cylinder with multiple feed port(according to actual needs),large discharge port, air port, access port, in machine sampling device.

Mixing cylinder material: manganess steel, stainless steel, large mixer can the manganese steel lining stainless steel plate.(the user can according to the conditions need to specify the corresponding material)

Technical Parameters:

parameter                   model HSS50 HSS200 HSS500 HSS1000 HSS2000 HSS4000 HSS6000
all capacity(L) 50 200 500 1000 2000 4000 6000
rated stir volume(L) 25-27 100-130 250-280 500-600 1000-1200 2000-2300 3000-6000
main power(kw) 2.2 4 7.5 15 30 45 55
Auxiliary power(kw) 0.75 1.1 1.5 3 7.5 15 15
Electric putter(kw) manual operation manual operation 0.55 0.55 0.75 0.75 0.75
disperser(branch) 4 8 8 8 10 12 14
weight(kg) 200 300 950 2100 3200 4300 5900
size(mm)L*W*H 1220*480*780 1600*760*830 2300*1060*1160 2670*900*1400 3320*1780*1690 4400*1960*1860 4435*2200*2310
Picture:
